High-performance fuel dispenser TANKER is intended for re-equipping a tank vehicle into a fuel truck and is intended for the installation on the petrol tanker or fueling trailer frame, etc. Due to the use of high-performance pumps the fuel filling time decreases by 2-3 times (depends on the pump type). Suitable for diesel fuel or petrol. The dispenser is compact, suitable for a car, has a convenient cover with sealing and stops.
The dispenser TANKER includes: pump, fuel meter, filter located in the locking cabinet preventing water and dirt ingress.
Standard scope of delivery
- A self-priming pump for oil pumping (from 50 to 150 lpm and up to 500 lpm, depends on the dispenser set and the used pump type)
- Pump supply voltage – 220, 380, 12 or 24V (or diesel or petrol internal combustion engine)
- Self-priming lift (depth) — up to 4 meters.
- Metal cabinet locked by key.
- Mechanical fuel amount meter (by order — electronic system of fuel dispensing by cards).
- Discharge hose— 4 meters, 19, 25 or 38 mm.
- Fuel coarse filter.
- Manual dispensing valve (automatic — by order).
Technical characteristics
|
Name |
Performance lpm, not more |
Fuel type |
Supply |
Precision class |
Filtration degree, micron |
Operation mode |
Type ofmeter |
|
Tanker 50 ABF-24/12 MT 1.0 |
50 |
MT/DF |
24Vor 12V |
1% |
10 |
30 min |
MG80 |
|
Tanker 70 ABF-24/12 DF 1.0 |
70 |
MT/DF |
24Vor 12V |
1% |
10 |
30 min |
MG80 |
|
Tanker 50 ABF-24/12 MT 0.5 |
50 |
MT/DF |
24Vor 12V |
0.5% |
10 |
30 min |
DD 25 |
|
Tanker 70 ABF-24/12 DF 0.5 |
70 |
MT/DF |
24Vor 12V |
0.5% |
10 |
30 min |
DD25 |
|
Tanker 70ABF-220V MT 1.0 |
70 |
MT/DF |
220V |
1% |
10 |
30 min |
MG80 |
|
Tanker 70ABF-220V MT 0.5 |
70 |
MT/DF |
220 V |
0.5% |
10 |
30 min |
DD25 |
|
Tanker 110ABF-220V MT 1.0 |
110 |
MT/DF |
220V |
2% |
100 |
30 min |
FR901 |
|
Tanker 50ABF-24/12 MT 1.0 |
50 |
DF |
24Vor 12V |
1% |
30 |
30 min |
К33 |
|
Tanker 50ABF-24/12 MT 0.5 |
50 |
DF |
24Vor 12V |
0.5% |
30 |
30 min |
DD25 |
|
Tanker 85ABF-24/12 MT 1.0 |
85 |
DF |
24Vor 12V |
1% |
30 |
30 min |
К33 |
|
Tanker 85ABF-24/12 MT 0.5 |
85 |
DF |
24Vor 12V |
0.5% |
30 |
30 min |
DD25 |
|
Tanker 100ABF-220 DF 1.0 |
100 |
DF |
220V |
1% |
30 |
Not limited |
К33 |
|
Tanker 100ABF-220 DF 0.5 |
100 |
DF |
220V |
0.5% |
30 |
Not limited |
DD25 |
|
Tanker 150ABF-220 DF |
150 |
DF |
220 |
0.5% or 0.25% |
30 |
Not limited |
PPO -40/ OGM-40 / M -40-1 |
|
Tanker 200ABF-220 DF |
200 |
DF |
220 |
0.5% or 0.25% |
30 |
Not limited |
PPO -40/ OGM-50 / M -40-1 |
|
Tanker 300ABF-220 DF |
300 |
DF |
220 |
0.5% or 0.25% |
30 |
Not limited |
PPO -40/ OGM-50 / M -40-1 |
|
Tanker 400ABF-380 DF |
400 |
DF/MT |
380 |
0.5% or 0.25% |
30 |
Not limited |
PPO -40/ OGM-50 / M -50-1 |
|
Tanker 400ABF-380 DF |
550 |
DF/MT |
380 |
0.5% or 0.25% |
30 |
Not limited |
PPT -65/ OGM-80 / M -80-1 |
|
Tanker 150ABF-ICE DF |
150 |
DF |
ICE Diesel |
0.5% or 0.25% |
30 |
Not limited |
PPO -40/ OGM-50 / M -40-1 |
|
Tanker 400ABF-ICE DF |
400 |
DF |
ICE Diesel |
0.5% or 0.25% |
30 |
Not limited |
PPO -40/ OGM-50 / M -50-1 |
|
Tanker 550ABF-ICE DF |
550 |
DF |
ICE Diesel |
0.5% or 0.25% |
30 |
Not limited |
PPT -65/ OGM-80 / M -80-1 |
|
Name |
Performance lpm, not more |
Fuel type |
Supply |
Precision class |
Filtration degree, micron |
Operation mode |
Type ofmeter |
|
Tanker 900ABF-ICE DF |
800 |
DF/Oil |
ICE Diesel |
0.5% or 0.25% |
30 |
Not limited |
PPT -80/ OGM-80 / М-80N-1 |
|
Tanker 100ABF-N/A DF |
100 |
DF/MT |
The fueler pump is used |
0.5% or 0.25% |
30 |
Not limited |
PPO-25/DD-25/ OGM-25 / M -40-1 |
|
Tanker 400ABF-N/A DF |
400 |
DF/MT |
The fueler pump is used |
0.5% or 0.25% |
30 |
Not limited |
PPO -40/ OGM-50 / M -50-1 |
|
Tanker 800ABF-N/A DF |
800 |
DF/MT |
The fueler pump is used |
0.5% or 0.25% |
30 |
Not limited |
PPV -80/ OGM-80 / М-80N-1 |
